Dynamic Enhanced Signaling


The Dynamic sign (PPDY) in the BTR range, has a low thickness and is made up of two aluminium signs with folded dropped edges, assembled using an elastomer seal.
Front finish: Polyester powder powder coating, black color RAL 9005.
Rear surface finish: Polyester powder powder coating, silver gray color RAL 9006.
It is equipped with 3 m of cable.
Rear fixing using double rail.
The symbol is outlined with red LEDs on the outside and yellow LEDs on the inside.
The lifetime of a LED is greater than 100 000 hours.
Red and yellow LEDs are connected in networks of 5 LEDs, ensuring continuous operation of the lighting element.
The panel must be connected to a power source: 230 V, on public lighting, or solar.
This type of sign can be manufactured with the road symbol of your choice, and can be supplied with 2 alternating symbols.
Flash mode operation.




focus2

1 panel 1 symbol:

Flashing mode.
focus2

1 panel 2 symbols:

Alternating Operating mode.
We ensure that the information displayed to road users if the most accurate, while optimizing visual impact thanks to a continuous alternance of symbols.
focus2

Electronics fully encapsulated in resin:

Our innovative and rigorously tested process allows our electronic devices to achieve an IP68 rating, providing maximum protection against dust and water ingress.
focus2

Qualified & sorted LEDs (High intensity & high efficiency):

  • High luminous efficiency.
  • Reduced consumption.
  • Lifespan +50%.



TTS ADVANTAGES:

  • Thin box (5 cm) : Designed to offer better integration in urban environments.
    The listel and the symbol are materialized by high brightness LEDs on a matt black background.
  • Single or double symbols: This type of sign is entirely adaptable to your needs.
    Up to 2 alternating symbols of your choice.
  • Superior visual impact:The reinforcement of the symbol by LEDs, and its square /rectangular shape on a black background allow for a better visual impact of the symbol. No more rivets, only the message on the front !

Dynamic Enhanced Police sign – BTR RANGE – Single Symbol

The enhanced Police sign (PPRF) in the BTR range, has a low thickness and is made up of two aluminium signs with folded dropped edges, assembled using an elastomer seal.Epoxy paint finish, silver-grey colour (metal).It is equipped with 3 metres of cable.Rear fixing using double rail....
ppdy_btr_simple_symbole-trame2

Dynamic Enhanced Police sign – BTR RANGE – Double Symbol

The enhanced Police sign (PPRF) in the BTR range, has a low thickness and is made up of two aluminium signs with folded dropped edges, assembled using an elastomer seal.Epoxy paint finish, silver-grey colour (metal).It is equipped with 3 metres of cable.Rear fixing using double rail....
ppdy_btr_1

Dynamic Enhanced Police sign – BTR RANGE – Specific Formats

The enhanced Police sign (PPRF) in the BTR range, has a low thickness and is made up of two aluminium signs with folded dropped edges, assembled using an elastomer seal.Epoxy paint finish, silver-grey colour (metal).It is equipped with 3 metres of cable.Rear fixing using double rail....
ppdybtr_b30

Dynamic Enhanced Police sign – BTR RANGE – Other Formats

The enhanced Police sign (PPRF) in the BTR range, has a low thickness and is made up of two aluminium signs with folded dropped edges, assembled using an elastomer seal.Epoxy paint finish, silver-grey colour (metal).It is equipped with 3 metres of cable.Rear fixing using double rail....
ppdybtr_autres
